Create pattern in javascript to implement in gojs

GoJS
1

Dear friends,

I want to create a pattern like below:

https://www.ultraplay.com/products/freestanding/trike-hazard-barrier-sign

using the below document
https://gojs.net/latest/intro/brush.html#PatternBrushes
(Pattern Brushes)
I wrote the code like below:

function makePattern() {
var patternCanvas = document.createElement(‘canvas’);
patternCanvas.width = 50;
patternCanvas.height = 100;
var pctx = patternCanvas.getContext(‘2d’);

pctx.fillStyle = “yellow”;
pctx.moveTo(20,90);
pctx.lineTo(40,90);
pctx.lineTo(20,0);
pctx.lineTo(0,0);
pctx.fill();
return patternCanvas;
}

it did not come well pls correct me to create exactly same like above hazard symbol.

Thanks and Regards,
Syed Abdul Rahim

2

You need to fill it with black, and you need to make sure the corners have yellow in them.

  function makePattern() {
    var patternCanvas = document.createElement('canvas');
    patternCanvas.width = 40;
    patternCanvas.height = 40;
    var pctx = patternCanvas.getContext('2d');

    pctx.fill = "black";
    pctx.fillRect(0, 0, 40, 40);

    pctx.lineWidth = 14;
    pctx.strokeStyle = "yellow";

    pctx.beginPath();
    pctx.moveTo(-60, -20);
    pctx.lineTo(20, 60);
    pctx.stroke();

    pctx.beginPath();
    pctx.moveTo(-20, -20);
    pctx.lineTo(60, 60);
    pctx.stroke();

    pctx.beginPath();
    pctx.moveTo(20, -20);
    pctx.lineTo(100, 60);
    pctx.stroke();

    return patternCanvas;
  }
3

Thanks Mr.walter. after finishing this diagram I gave make as svg it came as black box no pattern like this… I gave below commands.

function saveAsSvg(){
var image = diagram.makeSVG({
scale: 1,
size: new go.Size(3000,1000)
});

var s = new XMLSerializer();
var str = s.serializeToString(image);
var tab = window.open(‘about:blank’, ‘_blank’);
//-----------to open svg----------------------------
tab.document.write("

’’+str+"
");
}

pls check and tell me did I made any mistake?

Thanks and Regards,
Syed Abdul Rahim

4

I just tried this:

<!DOCTYPE html>
<html>
<head>
<title>Minimal GoJS Sample</title>
<!-- Copyright 1998-2019 by Northwoods Software Corporation. -->
<meta charset="UTF-8">
<script src="go.js"></script>
<script id="code">
  function makePattern() {
    var patternCanvas = document.createElement('canvas');
    patternCanvas.width = 40;
    patternCanvas.height = 40;
    var pctx = patternCanvas.getContext('2d');

    pctx.fill = "black";
    pctx.fillRect(0, 0, 40, 40);

    pctx.lineWidth = 14;
    pctx.strokeStyle = "yellow";

    pctx.beginPath();
    pctx.moveTo(-60, -20);
    pctx.lineTo(20, 60);
    pctx.stroke();

    pctx.beginPath();
    pctx.moveTo(-20, -20);
    pctx.lineTo(60, 60);
    pctx.stroke();

    pctx.beginPath();
    pctx.moveTo(20, -20);
    pctx.lineTo(100, 60);
    pctx.stroke();

    return patternCanvas;
  }

  function init() {
    var $ = go.GraphObject.make;

    myDiagram =
      $(go.Diagram, "myDiagramDiv");

    myDiagram.nodeTemplate =
      $(go.Node, "Auto",
        $(go.Shape,
          { fill: $(go.Brush, "Pattern", { pattern: makePattern() }) }),
        $(go.TextBlock,
          { margin: 8, stroke: "orange" },
          new go.Binding("text"))
      );

    myDiagram.linkTemplate =
      $(go.Link,
        $(go.Shape),
        $(go.Shape, { toArrow: "OpenTriangle" })
      );

    myDiagram.model = new go.GraphLinksModel(
    [
      { key: 1, text: "Alpha", color: "lightblue" },
      { key: 2, text: "Beta", color: "orange" },
      { key: 3, text: "Gamma", color: "lightgreen" },
      { key: 4, text: "Delta", color: "pink" }
    ],
    [
      { from: 1, to: 2 },
      { from: 1, to: 3 },
      { from: 2, to: 2 },
      { from: 3, to: 4 },
      { from: 4, to: 1 }
    ]);
  }

  function test() {
    var svg = myDiagram.makeSvg({ scale: 1 });
    console.log(new XMLSerializer().serializeToString(svg));
    document.body.appendChild(svg);
  }
</script>
</head>
<body onload="init()">
  <div id="myDiagramDiv" style="border: solid 1px black; width:100%; height:400px"></div>
  <button onclick="test()">Test</button>
</body>
</html>

and after clicking the “Test” Button it produced this:

image.png634×574 27.2 KB

Furthermore, the SVG text written to the console, after sticking into an “.svg” file, produced a valid SVG file that renders correctly in four different browsers that I tried.

Hmmm, I cannot upload an SVG image file to the forum, but here’s the text in it:

5

Thanks Mr.Walters
