I’ve upgraded to Angular 16 and now my gojs diagram breaks when adding a new shape to the diagram.
It breaks here
` public diagramModelChange(changes: go.IncrementalData): void {
// when setting state here, be sure to set skipsDiagramUpdate: true since GoJS already has this update
// (since this is a GoJS model changed listener event function)
// this way, we don’t log an unneeded transaction in the Diagram’s undoManager history
const appComp = this;
this.state = produce(this.state, draft => {
// set skipsDiagramUpdate: true since GoJS already has this update
// this way, we don't log an unneeded transaction in the Diagram's undoManager history
draft.skipsDiagramUpdate = true;
draft.diagramNodeData = DataSyncService.syncNodeData(changes, draft.diagramNodeData, appComp.observedDiagram.model) as any;
draft.diagramLinkData = DataSyncService.syncLinkData(changes, draft.diagramLinkData, appComp.observedDiagram.model as any) as any;
draft.diagramModelData = DataSyncService.syncModelData(changes, draft.diagramModelData) as any;
// If one of the modified nodes/links was the selected node used by the inspector, update the inspector selectedNodeData object
const modifieDatas = changes.modifiedNodeData || changes.modifiedLinkData;
if (modifieDatas && draft.selectedNodeData) {
for (const data of modifieDatas) {
const nodeKeyProperty = appComp.myDiagramComponent.diagram.model.nodeKeyProperty as string;
if (data[nodeKeyProperty] === draft.selectedNodeData[nodeKeyProperty]) {
draft.selectedNodeData = data;
}
}
}
});
`
specifically it breaks on the line :
draft.diagramNodeData = DataSyncService.syncNodeData(changes, draft.diagramNodeData, appComp.observedDiagram.model) as any;
with the error TypeError: Cannot read properties of undefined (reading '23')
, which does not help much…
I have also upgraded immer.js to version 10 (was on 9 before).
I’m on gojs 2.3.1 and gojs-angular 2.0.6
Can you let me know if something needs changing or if gojs-angular is not compatible with these packages ? My code was working just fine before the upgrade, so I’m not doing anything wrong here.
