Panel Background does not correctly wrap TextBlock (Tooltip)

GoJS
1

Hey,

using a Panel with background-color and adding a TextBlock to it, for some reason the background does not wrap the TextBlock correctly.

TooltipCode:

toolTip: new Adornment(Panel.Spot, {
      background: 'white',
}).add(new TextBlock().bind('text', 'name')),

Image:

image626Ɨ632 7.33 KB

For longer texts, the problem is even worse.
Any Idea what could cause this problem?

Thanks in advance

2

Do you have the same behavior in different browsers or on different types of hardware or platforms?

3

Are you using any custom fonts?

What happens if you remove all CSS from your page?

This works as Iā€™d expect: Edit fiddle - JSFiddle - Code Playground

1 Like
4

Actually, it seems like I only have this problem with Chromium (Chrome / Vivaldi). Within Firefox and Safari, everything looks ok.

Firefox / Safari:

Chromium:

5

Does the problem go away in Chrome when using GoJS v2.3.7?

6

I discovered the solution to the issue today. Adjusting the CSS (diagram div) settings to letter-spacing: normal; successfully resolved the problem.
